Hafele Touch Latch Automatic Spring Latch 245.56.901
Hafele Touch Latch Automatic Spring Latch
245.56.901
Spring Latch isĀ suited for applications requiring quick and secure engagement and disengagement of doors, compartments, or panels. When necessary, the spring-loaded bolt can be secured in the open position, and by twisting the lever, the bolt can then close firmly with the help of the spring.
Spring Latch Function - consists of a bracket on one surface, a notched plate on the other, and a pin connecting the two surfaces. Latches are mechanical devices used to affix two distinct parts together to stop.
Specifications:
- Material: Steel
- Latch Length: 78mm
- Latch Width: 36mm
- Latch Height: 20mm
- Strike Length: 31mm
- Strike Width: 13mm
- Strike Projection: 20mm
- Finish: Bright galvanized
Note:Ā Not suitable for use with hinges with the soft closing mechanism.
Original: $7.21
-70%$7.21
$2.16More Images
Hafele Touch Latch Automatic Spring Latch 245.56.901
Hafele Touch Latch Automatic Spring Latch
245.56.901
Spring Latch isĀ suited for applications requiring quick and secure engagement and disengagement of doors, compartments, or panels. When necessary, the spring-loaded bolt can be secured in the open position, and by twisting the lever, the bolt can then close firmly with the help of the spring.
Spring Latch Function - consists of a bracket on one surface, a notched plate on the other, and a pin connecting the two surfaces. Latches are mechanical devices used to affix two distinct parts together to stop.
Specifications:
- Material: Steel
- Latch Length: 78mm
- Latch Width: 36mm
- Latch Height: 20mm
- Strike Length: 31mm
- Strike Width: 13mm
- Strike Projection: 20mm
- Finish: Bright galvanized
Note:Ā Not suitable for use with hinges with the soft closing mechanism.
